Model 2504 Multiband Transceiver with FPGA Record/Playback System

This product is no longer available for new designs. Please see Pentek's series of RTS 2700 recording and playback instruments.

Block Diagram




Life Cycle Management

Ordering & Warranty


  • Highly scalable platform from 2 to 40 transceiver channels
  • 14-bit, 105 MHz A/Ds
  • 16-bit, 500 MHz D/As
  • Real-time recording to RAID and JBOD arrays at up to 160 MBytes/sec
  • Storage to 6 terabytes and higher
  • 1 GHz G4 PowerPC
  • Multiple Xilinx Virtex-II & Virtex-II PRO FPGAs
  • Optimized GateFlow FPGA IP Cores optionally available
  • Custom FPGA Development with GateFlow Design Kit
  • 64-bit/66 MHz PMC site and VIM site
  • Multiband decimation range from 2 to 1,048,576 (with DDC core -421 installed)
  • Ethernet link to popular hosts
  • SystemFlow Recording Software
  • SystemFlow File Manager
  • Windows or Linux host platform
  • Ideal for radar, wireless, SIGINT, telecom and satcom


Model 2504


Model 2504 Block Diagram

Please refer to the product datasheet for a larger version of the block diagram

Hardware and Software Manuals - ( top )

Please note that some hardware and software manuals are used for more than one Pentek product. Although the model numbers given in the description of each manual below may vary, these manuals are all used for the product described on this web page.

Part No.
800.25040 Operating Manual RTS 2504 - Obsolete - Real-Time Signal Processing & Recording Dev Platform 1.1 (10/5/2007)
811.25040 Programmer's Reference RTS 2504 - Obsolete 1.1 (10/1/2007)
