Development Tactics and Techniques for Small Form Factor (SFF) RF Signal Recorders

by Chris Tojeira, Recording Systems Director

While real-time recording of a gigahertz or more of RF bandwidth is commonly available in 19" rack-mountable systems, shrinking this capability into a form factor suitable for UAVs, aircraft pods, or other confined spaces has proven challenging for the industry.

Pentek's QuickPac drive pack provides up to 30 TB of solid state storage in a small package


Learn about the engineering considerations and design techniques used to develop a small form factor (SFF) rugged recorder that can handle the extremely high data rates associated with very wide bandwidth RF signal recording.



Product Focus

200 MS/sec RF/IF Extreme 1/2 ATR Recorder

Features

  • Rugged 1/2 ATR MIL-spec chassis
  • Designed for harsh mechanical and thermal environments
  • Environmentally sealed
  • Internally conduction-cooled
  • Fully sealed for RF emissions with EMI power line filter
  • MIL-STD circular connectors
  • Compact and lightweight design - 22 lb (10kg)
  • Ideal for UAVs, military vehicles, aircraft pods and outdoor environments
  • RF/IF recording with phase coherent 200 MHz 16-bit A/Ds and DDCs
  • Sustained real-time record rates up to 4 GB/s
Model 2586
Model 2586

Talon RTX Extreme Systems Family



Product Focus

8-Channel A/D & D/A Zynq UltraScale+ RFSoC Processor

Features

Model 6001
Model 6001

Quartz family of Xilinx Zynq UltraScale+ RFSoC FPGAs



Product Focus

1-Slot 3U VPX Development Chassis for Quartz Products

Features

  • Ideal development platform for Pentek's Model 5950 8-Channel A/D & D/A Zynq UltraScale+ RFSoc Processor
  • 1-slot, small footprint development chassis
  • Optional dual MPO interfaces support 100 GigE
  • Supports VITA-66.4
  • Compatible with the Quartz product family
Model 8257
Model 8257




Product Focus

1-Ch. 6.4 GHz or 2-Ch. 3.2 GHz A/D, 2-Ch 6.4 GHz D/A Kintex UltraScale

Features

Model 71141
Model 71141

Jade Kintex UltraScale FPGA Family



Product Focus

3.6 GS/sec Ultra Wideband RF/IF Extreme 1/2 ATR Recorder

Features

  • Rugged 1/2 ATR MIL-spec chassis
  • Designed for harsh mechanical and thermal environments
  • Environmentally sealed
  • Internally conduction-cooled
  • Fully sealed for RF emissions with EMI power line filter
  • MIL-STD circular connectors
  • Compact and lightweight design - 22 lb (10kg)
  • Ideal for UAVs, military vehicles, aircraft pods and outdoor environments
  • Capable of recording RF/IF frequencies to 2.8 GHz
  • Ultra Wideband recording with 3.6 GHz 12-bit A/D
  • Selectable 1.8 GHz dual channel mode
Model 2589
Model 2589

Talon RTX Extreme Systems Family



Product Focus

8 Channel A/D & D/A Zynq UltraScale+ RFSoC Processor

Features

Model 5950
Model 5950

Quartz family of Xilinx Zynq UltraScale+ RFSoC FPGAs



Product Focus

2-Ch 500 MHz A/D with DDC & 2-Ch 800 MHz D/A with DUC, Kintex UltraScale

Features

Model 71851
Model 71851

Jade Kintex UltraScale FPGA Family



Model 4283

Still working reliably, 24 years later...

Once upon a time (May of 1994, to be exact), a customer purchased a Pentek Model 4283 Single TMS320C30 Processor. It has worked reliably for 24 years. Recently, the customer sent it back to us. Not for a repair, but for re-certification (required by an audit). It passed all standard tests and all certification tests and is ready for shipment back to the customer, where it will resume its long and reliable work life.

It is easy to get excited about all of Pentek's newest products, but there are reasons to get excited about Pentek's older products. In this case, a long life of flawless operation.

Pentek offers lifetime support on its products — even discontinued products like this one. As long as replacement parts are available, we will repair it. But, of course, we strive to create products so dependable that repairs are not necessary! Like this one.
