Because they are effective in handling the extreme breadth of I/O functions required, open architecture embedded systems for military or aerospace applications have always relied on mezzanine, or daughter cards, to provide flexibility and modularity.

"The Pentek Onyx® Model 71760 Four-Channel, 200 MHz, 16-bit A/D XMC software radio board is also available in PCIe, CompactPCI, and OpenVPX form factors."

Features Complete radar and software radio interface solution Supports Xilinx Virtex-6 LXT and SXT FPGAs Two 500 MHz 12-bit A/Ds Two multiband DDCs (digital downconverters) Two 800 MHz 16-bit D/As One DUC (digital upconverter) Multiboard programmable beamformer Up to 2 GB of DDR3 SDRAM or 16 MB of QDRII+ SRAM Sample clock synchronization to an external system reference

Model 71651

Features Complete radar and software radio interface solution Supports Xilinx Virtex-6 LXT and SXT FPGAs Four 1.25 GHz 16-bit D/As Four digital upconverters Extended interpolation range from 2x to 1,048,576x Programmable output levels 250 MHz max. output bandwidth 2 GB of DDR3 SDRAM

Model 78671

Features Complete Serial FPDP record and playback system Up to eight I/O channels in a single 4U or 5U 19 inch industrial rackmount PC server chassis

RTS 2716

• Supports Flow Control, CRC, and Copy/Loop Mode as a receiver and transmitter
• Supports 1.0625, 2.125 and 2.5 GBaud link rates
• Copper, single-mode and multi-mode fiber interfaces available
• Real-time sustained recording rates up to 2 GB/sec in 8-channel configuration
• Up to 20 terabytes of storage to NTFS RAID disk array

Features Designed to operate under conditions of shock and vibration Portable system measures 16.9" W x 9.5"D x 13.4" H Rugged aluminum alloy chassis

RTR 2736

• Lightweight, approximately 30 pounds
• Shock-and vibration-resistant SSDs perform well in vehicles, ships and aircraft
• Up to 8 I/O channels
• Supports Flow Control, CRC, and Copy/Loop Mode as a receiver and transmitter

Features Designed to operate under conditions of shock and vibration Sample rates up to 3.2 GHz in single-channel mode

RTR 2749

• Sample rates up to 1.6 GHz in dual-channel mode
• Capable of recording RF/IF frequencies to 2.8 GHz in dual-channel mode
• 12-bit A/D, with 12 and 8 bit packing modes
• Real-time sustained recording rates of up to 3200 MB/sec
• 4 U 19 inch industrial rugged rackmount PC server chassis

Features Designed to operate under conditions of shock and vibration Complete Serial FPDP record and playback system

RTR 2756

• Up to 8 I/O channels in a single 4U 19 inch rugged rackmount PC server chassis Removable SSDs
• Up to 20 terabytes of storage to NTFS RAID disk array
• Copper, single-mode and multi-mode fiber interfaces available
• Real-time sustained recording rates up to 2 GB/sec in 8-channel configuration
• Supports Flow Control, CRC, and Copy/Loop Mode as a receiver and transmitter

• Expands interpolation range from 2x to 1,048,576x
• Simplifies beamformed transmit arrays with multichannel synchronous operation
• Provides turnkey signal upconversion
• Eases complex waveform generation with minimum programming using linked-list DMA controllers

• Sample rates up to 3.2 GHz with real-time sustained recording rates of up to 3.2 GB/sec
• Capable of recording RF/IF frequencies up to 2.8 GHz
• SystemFlow® GUI with signal viewer analysis tool
• Up to 20 terabytes with front-panel removable SSD storage to NTFS RAID
